| Brand Name : | HSG LASER |
| Model Number : | HS-G3015A |
| Certification : | 1.CE certificate 2.ISO certificate 3.FDA certificate |
| Price : | |
| Delivery Time : | 3 to 30 days depending on different models and quantity |
| Payment Terms : | T/T, Western Union, Money Gram, Cash |
| Supply Ability : | 3000 SETS/YEAR |
Specially used for cutting 0.5-12mm carbon steel, 0.5-10mm stainless steel, galvanized steel, electrolytic zinc-coated steel sheet, silicon steel,0.5-3mm aluminum, 0.5-2mm brass and red copper and other kinds of thin metal sheets(The thickness and materials depend on the brand fiber laser source).
Specification
Working table（mm） | 1500*3000 | Laser power(W) | 1000 |
Weight（kg） | 6000 | Max. running speed | 80m/min |
Machine body size（mm） | 7900×2950×1900 | Max.Acceleration Speed | 1G |
Features
1. Double tables save the materials feeding and collecting time.
2. Full-protection cover reduces laser radiation.
3. Intelligent automatic oil-feeding device extends the lifespan of the transmitting components.
4. High accelarated speed enhances the working efficiency.
5. Specially used for cutting 0.5-12mm carbon steel, 0.5-10mm stainless steel, galvanized steel, electrolytic zinc-coated steel sheet, silicon steel,0.5-3mm aluminum, 0.5-2mm brass and red copper and other kinds of thin metal sheets(The thickness and materials depend on the brand fiber laser source).
Technical parameter
Work table area | 3000*1500mm |
Max running speed | 80m/min |
X/Y location precision | 0.05mm/m |
Power Supply | 380V 50Hz |
X/Y repeated location precision | ±0.03 |
Machine gross power | <20KVA |
Running Temperature | 0°C-40°C |
Running himidity | <90% |
Max. accelarated speed | 1G |
Transmitting structure | Precise pinion and rack, dual-drive transmitting |
Samples
|
|
